LF280K-V3
EVE LF280K-V3 cells 3.2V lifepo4 280Ah lifepo4 battery 280Ah lithium battery 8000 Cycle EVE 280Ah battery rechargeable eve LF280K-V3 prismatic 280Ah lithium battery 3.2V 280Ah EVE cells solar storage
- Model Name： LF280K
- Nominal Capacity： 280Ah
- Nominal Voltage： 3.2V
- Cycle Life： 8000 Cycles
- Data Sources： EVE's Laboratory
Overview
Specs
Safety Instructions
| Specification Parameters |
|---|
| Nominal Capacity |
280Ah
|
| Nominal Voltage |
3.2V
|
| Initial IR |
≤0.25mΩ
|
| Weight |
5490 g±300g
|
| Charging Cut-off Voltage |
3.65V
|
| Discharging Cut-off V oltage |
2.5V
|
| Operation Temperature |
0~60℃
|
| Discharging Temperature |
-30~60℃
|
| Storage Temperature |
0~35℃(1 Year) -20~45℃(1 month)
|
| Model Name |
LF280K-V3
|
| Cycle Life |
8000 Cycles
|
| Standard Charging Power |
448W
|
| Standard Discharging Power |
448W
|
| Height(H) with terminal |
207.2±0.5 mm
|
| Height(h) without terminal |
204.6±0.5 mm
|
| Length |
173.70.5 mm
|
| Thickness |
71.7±0.8 mm
|
<p><span style="color: rgb(64, 64, 64);">Introduction of </span><strong style="color: rgb(64, 64, 64);">EVE LF280K</strong></p><p><span style="color: rgb(64, 64, 64);">Model Name: LF280K</span></p><p><span style="color: rgb(64, 64, 64);">Nominal Capacity: 280Ah</span></p><p><span style="color: rgb(64, 64, 64);">Nominal Voltage: 3.2V</span></p><p><span style="color: rgb(64, 64, 64);">Cycle Life: 8000 Cycles</span></p><p><span style="color: rgb(64, 64, 64);">Data Sources: EVE's Laboratory</span></p><p><span style="color: rgb(64, 64, 64);">Advantages of</span><strong style="color: rgb(64, 64, 64);"> EVE LF280K</strong></p><p><span style="color: rgb(64, 64, 64);">1. Automated: Automated production.</span></p><p><span style="color: rgb(64, 64, 64);">2. Ultra-Safe: Explosion-proof/no leakage.</span></p><p><span style="color: rgb(64, 64, 64);">3. Stable: Low IR/High CR/Discharge steadily.</span></p><p><span style="color: rgb(64, 64, 64);">4. Customized Custom-made: EVE offers customization service with customer demand.</span></p><p><span style="color: rgb(64, 64, 64);">5. Super Long: </span><strong style="color: rgb(64, 64, 64);">EVE LF280K </strong><span style="color: rgb(64, 64, 64);">battery has an</span><strong style="color: rgb(64, 64, 64);"> </strong><span style="color: rgb(64, 64, 64);">ultra-long life cycle.</span></p><p><span style="color: rgb(64, 64, 64);">6. Environmentally Friendly: </span><strong style="color: rgb(64, 64, 64);">EVE LF280K </strong><span style="color: rgb(64, 64, 64);">has passed environmental system certification.</span></p><p><span style="color: rgb(64, 64, 64);">Specifications of </span><strong style="color: rgb(64, 64, 64);">EVE LF280K battery</strong></p><p><span style="color: rgb(64, 64, 64);">Model: LF280K</span></p><p><span style="color: rgb(64, 64, 64);">Nominal Voltage: 3.20V</span></p><p><span style="color: rgb(64, 64, 64);">Capacity: 280Ah</span></p><p><span style="color: rgb(64, 64, 64);">Nominal weight: 5420±300g</span></p><p><span style="color: rgb(64, 64, 64);">Dimension: H: 207.2±0.5mm W: 173.7±0.5mm T: 72±1mm</span></p><p><span style="color: rgb(64, 64, 64);">Applications of </span><strong style="color: rgb(64, 64, 64);">EVE LF280K</strong></p><p><strong style="color: rgb(64, 64, 64);">EVE LF280K</strong><span style="color: rgb(64, 64, 64);"> is wildly applicable to various scenarios, such as new energy passenger cars, new energy buses, etc.</span></p>
