CR17450
EVE CR17450 Li/MnO2 battery 3V 2400mAh Smart Meter/Smart Life/Automotive Electronics/IoT Solotion
-
3 Nominal Voltage（V）
-
2400 Nominal Capacity（mAh)
-
5 Standard discharge current(mA)
-
-40~+70℃ Working Temperature(℃)
-
17.0×45.0 Dimensions (mm)
-
23.5 Weight (g)
Application Scenario
Smart Metering,Automotive Electronics,Internet of Things,Smart Security,Smart Healthcare
Product Certification
Origin of Shipment：
Chinese Factory Direct -
Long Service Life
-
Multi Application Scenario
-
Comprehensive Solutions
-
Low Self-discharge Rate
-
High Stability Voltage
-
High Energy Density
-
Ultra Wide Temperature Applications
-
Fully Certified
-
Product Selection
-
Product Introduction
-
Specifications
-
Safety Precautions
Product Selection
Product Introduction
-
World-leading, Sales and export volume ranks No. 1 for 8yrsEVE has supplied over 3.5 billion lithium primary batteries to the world
-
CR17450 3V 2400mAhHigh Pulse,Long Lifespan
Product CertificationMeet UL1642, UN38.3, ATEX, CE, ISO and other certificates
-
Intelligent Security Power Solutions12 years + long life, -40℃~85℃ ultra-wide temperature range
-
Comprehensive cylindrical battery solutionsIntelligent Smoke Sensor, Intelligent Door Lock, Combustible Gas Detection, Intelligent Home Appliance and other programs
-
Intelligent Security Power SolutionsOver 13 years of application verification, provide safe and reliable power supply for security equipment
-
Long lifespanExtremely long reliability life expectancy
Continuous Discharge CharacteristicsDischarge mode: 20mA continuous discharge, cutoff 1.0V
Temperature Change Pulse CurvePulse discharge curves at different temperatures
Specifications
| Model | CR17450/CR17450L |
| Nominal voltage | 3V |
| Nominal capacity | 2400mAh |
| Weight | 23.5g |
| Maximum Continuous Discharge Current | 1000mA |
| Maximum pulse discharge current | 2500mA |
| Recommended storage conditions | Temperature: 5℃~35℃, Humidity: less than 70%RH |
| Application Scenarios | Smart Metering, Smart Living, Automotive Electronics, Internet of Things, Smart Security |
| Working Temperature | -40~70℃ |
